Monitoring speed, frequency, voltage, current, oil pressure, coolant temperature, and fuel level, the modules will display warnings, shutdown and engine status information on the back-lit LCD screen and illuminated LED.
Front panel editing
LED and LCD alarm indication
Power Save mode
CAN and Magnetic Pick-up/Alt. versions available (specify on ordering)
PC and front panel configuration
6 Digital inputs
3 Analog inputs
6 Outputs (4 configurable on Magnetic Pick-up/Alt., 6 configurable on CAN version)
Configurable timers and alarms
Event Log (10)
Remote Start input
3 Phase generator monitoring
Current Monitoring and protection
Battery voltage monitoring
Comprehensive shutdown or warning on fault condition
Operating Voltage DC8.0V to DC35.0V, Continuous Power Supply.
Alternator Input Range 15V - 360 V AC (ph-N)
3-Phase4-Wire 26V - 620 V AC (ph-ph)
3-Phase3-Wire 15V - 360 V AC (ph-N)
Single-phase2-wire 15V - 360 V AC (ph-N)
Alternator Frequency 50/60Hz
Speed Sensor voltage VPP 2.2 - 100Vpp (Peak to peak)
Speed Sensor Frequency 10000Hz (max)
Start Relay Output 16Amp Controller Power Voltage Output
Fuel Relay Output 16Amp Controller Power Voltage Output
Programmable Relay Output 1 7Amp 250VAC Voltage Free Output
Programmable Relay Output 2 7Amp 250VAC Voltage Free Output
Programmable Relay Output 3 16Amp 250VAC Voltage Free Output
Programmable Relay Output 4 16Amp 250VAC Voltage Free Output
Case Dimension 210mm x 152 mm x 48 mm
Panel Cutout 186mm x 141mm
C.T. Secondary 5A Rated
Protection Level IP55:When waterproof rubber seal installed between the controller and panel fascia.
IP42: When a waterproof rubber seal is not installed between the controller and the panel fascia.
Insulating Intensity Object: input/output/power
Quote standard: IEC688-1992
Test way: AC1.5kV/1min leakage current:3mA
